Updated suspension
This €œSX € series features all-new Maestro rear suspension with added travel (145mm) for technical singletrack and rugged descents. The trunnion mount shock and Advanced Forged Composite rocker arm combine for a longer stroke that has a smooth, active feel, plus greater stiffness in the chassis for precision control. The rear suspension is paired with a longer travel 160mm fork, giving riders superior confidence and control on the descents.
Adjustable trail geometry
A three-position Maestro flip chip lets riders dial in frame geometry to suit their riding style and terrain. The high setting adds more ground clearance, a good option for tight, technical terrain. In the low setting, the head tube gets slacker and the bottom bracket drops, ideal for confident handling at higher speeds. The middle position is neutral. In addition, a new headset flip chip adjusts reach so you can easily achieve your preferred positioning.
Mixed wheel setup
A 29-inch front wheel provides speed, stability and front-end control on rough, technical trails. A 27.5-inch rear wheel adds agility and manoeuvrability to help riders rail corners, pop over features and show off their style.
Frameset | ALUXX SL-grade aluminium front and rear triangles, 145mm Maestro suspension, flip chip - Maestro 3, flip chip - headset, 12x148mm thru-axle |
---|---|
Fork | Fox 36 Float Rhythm, GRIP damper, 44mm offset, 160mm, 15x110 Kabolt, custom tuned for Giant |
Brakes | Shimano Deore BR-MT420, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm |
Tyres | [F] Maxxis Minion DHF, 29x2.5 WT, 60 tpi, EXO, TR [R] Maxxis Dissector 27.5x2.4 WT, 60 tpi, EXO TR, tubeless |
Rear mech | Shimano Deore |
Wheelset | Giant TRA 2, 29" wheelset, hookless aluxx wheelsystem, 30mm inner width, 40mm outer width |
Stem | Giant Contact SL 35 S:40mm, M:40mm, L:50mm |
Handlebar | Giant Contact TR35, 780x35mm, 20mm rise |
Shifters | Shimano Deore, 1x12 |
Cassette | Shimano Deore, 10x51 |
Chain | KMC X-12 |
Chainset | Praxis Cadet, 30t, 55mm chainline |
Bottom bracket | Praxis, press fit |
Saddle | Giant Romero |
Seat post | Giant Contact Switch Adjustable, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm |
Rear shock | Marzocchi Bomber Air, 185/55, custom tuned for Giant |
Tape grips | Giant Tactal Pro Single S:120mm, M:120mm, L:130mm |
