| Frameset | Lite IV - Hydroformed 6061 Double butted aluminium with integrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8" |
|---|---|
| Fork | Suntour AION 36X-Boost; 150mm travel; Tapered, 44mm fork offset |
| Brakes | SRAM DB8 4 piston hydraulic disc brake caliper with SRAM CenterLine 200mm rotor |
| Tyres | Maxxis Rekon; 29" x 2.4"; Kevlar bead, folding; 3C EXO MaxxTerra |
| Rear mech | SRAM NX Eagle |
| Wheelset | Merida Expert TR II; 28mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included); 29" |
| Headset | Acros ICR Merida external neck w/ Blocklock |
| Stem | Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - Stem length: 40mm (all sizes). GoPro & Supernova mount point. |
| Handlebar | Merida Expert eTR; 780mm wide; 20mm rise |
| Shifters | Limotech RM10 dropper post lever and SRAM NX Eagle 12 speed |
| Cassette | SRAM PG-1210 Eagle; 10-50 teeth; 12 speed |
| Chain | SRAM SX Eagle |
| Chainset | FSA 1x Steel chainring; 36 tooth chainset with Shimano FC-EM600; 165mm length crank all sizes with MRP 1x chainguide |
| Bottom bracket | Part of Shimano Steps motor |
| Saddle | Merida Expert SL with V-mount; including Merida minitool |
| Seat post | Merida Expert TR II; 34.9mm diameter; in-line; XS: 125mm - S: 150mm - M/L/XL: 200mm seat post travel |
| Motor | Shimano Steps EP801; 85Nm |
| Battery | Simplo Trend Power Internal Battery Gen 2; 750Wh |
| Rear shock | RockShox Super Deluxe Select |
| Tape grips | Merida Expert EC |
