| Frameset | Lite- Hydroformed 6066 triple butted aluminium, external battery. 142 x 12mm axle standard. Internal cable routing via Smart Entry ports. Max. tyre size 700 x 42c with mudguards |
|---|---|
| Fork | Suntour NEX-PM-DS; Coil; 63mm travel. Max. tyre size: 700 x 48c |
| Brakes | Hydraulic disc |
| Tyres | Continental Ride Tour; 622x42; reflective stripe - Continental Ride Tour; 622x42; reflective stripe |
| Rear mech | Shimano Altus M2000; SGS |
| Wheelset | Merida Comp TK; 20mm inner rim width; Aluminium |
| Headset | Merida 2346 Neck |
| Stem | Merida Expert; aluminium; 31.8mm diameter; 17 degree rise - Stem length: 80mm (XS/S), 90mm (M), 100mm (L), 110mm (XL) |
| Handlebar | Merida Expert; aluminium; 660mm wide; 15mm rise |
| Shifters | Shimano Altus rapidfire |
| Cassette | KMC e9S |
| Chain | KMC e9S |
| Chainset | Shimano CRE50; 38 tooth chainring with Shimano FC-E5010; 170mm length crank and chainguard |
| Bottom bracket | Part of Shimano Steps motor |
| Saddle | Merida Expert TK; V-mount |
| Seat post | Merida Expert; aluminium; 30.9mm diameter; 15mm lay back |
| Motor | 418 Wh |
| Tape grips | Merida Expert TK |
