Frameset | DT - 6061 double butted technoformed aluminium. BSA BB standard, 135 x 9mm QR axle standard. Mounting points for rack, mudguards and kickstand. Max. tyre size 700 x 42c |
---|---|
Fork | Suntour NEX; Coil; 63mm travel. Max. tyre size: 700 x 50c |
Brakes | V Brake |
Tyres | Merida K1171; 700x40C; wire bead - Merida K1171; 700x40C; wire bead |
Rear mech | Shimano RD-M310 |
Wheelset | Merida CC; 17mm inner rim width; Aluminium |
Headset | FSA TH888 |
Stem | Merida TK; aluminium; 25.4mm diameter; adjustable - Stem length: 100mm (all sizes) |
Handlebar | Merida CC; steel; 620mm width; 30mm rise |
Shifters | Shimano ST-EF500 |
Cassette | KMC NS8 |
Chain | KMC NS8 |
Chainset | Shimano TY301; 48-38-28 tooth chainset. Crank length: 170mm (S), 175mm (M/L,XL) |
Bottom bracket | FSA TH-7420ST-W, Cartridge Bearing |
Saddle | Merida Cross Sport |
Seat post | Merida TK; 27.2mm diameter; 13mm setback; 40mm seatpost suspension travel |
Tape grips | Merida EC |
Front mech | Shimano FD-TY510 |
