The original Big Trail was designed on the back of a napkin when several UK customers and Merida €™s German R&D team chewed the fat about what would make the perfect UK trail bike. The resulting bike received rave press reviews and delighted customers worldwide.
Since then Merida €™s R&D team have wowed the mountain bike world winning the coveted MBUK Bike of the year in both the Trail bike and Enduro bike categories.
Big Trail II takes many of those award-winning learnings:
A steeper seat angle (up from 75.5° to 76.5°) puts the rider in an efficient climbing position and shortens the top tube allowing Merida to extend the reach meaning the bike doesn't feel too long when you're pedalling in a seated position but provides plenty of stability on rough terrain.
The head angle goes from an already progressive 65.5° to 64.0° and when combined with a large 70mm BB drop (up from 66.5?mm), gives the feeling of €˜sitting in the bike €™ rather than €˜on it €™ providing plenty of stability and confidence when things get rowdy.
The geometry follows the Agilometer principles which means most sizes work for most body sizes so riding style can be factored in. If you want to go crazy fast, take the longer size, for agility, take a shorter size.
Frameset | TFS - 6061 double butted technoformed aluminium, smooth welding, Boost axle standard, tapered head tube, inboard disc mounts, internal cable routing, BSA BB standard, Max tyre size 29" x 2.5" |
---|---|
Fork | Rock Shox Psylo Silver RC; Air; 140mm travel; platform |
Brakes | Shimano MT410 |
Tyres | Maxxis Minion DHF; 29" x 2.5"; Kevlar bead; TR EXO Dual, Maxxis Dissector; 29" x 2.4"; Kevlar bead; TR EXO Dual |
Rear mech | Shimano CUES U6000; GS |
Wheelset | Merida Comp TR; 29mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included) |
Headset | Acros ICR Merida external neck; Upper and lower IPS sealing |
Stem | Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise - Size - 40 mm |
Handlebar | Merida Expert TR II; aluminium; 780mm wide; 18mm rise |
Shifters | Shimano CUES U6000 |
Cassette | KMC xGlide |
Chain | Shimano LG300; 11-48 teeth; 10 speed |
Chainset | Merida Expert TR II; 32 teeth With Merida Expert TR ISCG05 - 165mm XShort and Short; 170mm Mid, Long and Xlong |
Saddle | Merida Comp SL; V-mount |
Seat post | Merida Expert TR II; 34.9mm diameter; 0mm layback; XShort: 150mm seat post travel - Short: 170mm seat post travel - Mid/Long: 200mm seat post travel - XLong: 230mm seat post travel |
Tape grips | Merida Comp EC |
