Merida's expertise for over 50 years has been building bombproof aluminium hardtails.
The latest generation follows modern mountain bike trends - a longer reach combined with a shorter stem. The geometry features a steeper seat angle and slacker head angle for greater offroad capability but without compromising everyday usability.
The sophisticated TFS frames feature:
full internal cable routing for a clean, neat set up,
tapered headtube offering future upgrade potential
inboard disc brake mounts protect the brake and maximise stopping power
dropper post ready
New XXS Big Seven size extends the wide range of sizes; Big Nine for taller riders, Big Seven for shorter riders. Riders in the middle can take riding style into account - for speed and efficiency choose a Big Nine, for agility choose a Big Seven.
Frameset | TFS V - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 29" x 2.4" |
---|---|
Fork | RockShox Judy GOLD; Air; 120 mm travel Lockout; 46mm fork offset |
Brakes | Hydraulic Disc Shimano MT200; hydraulic brake with Shimano RT10; 160 mm & Shimano MT200; hydraulic brake with Shimano RT10; 160 mm |
Tyres | Kenda Booster; 29x2.4" & Kenda Booster; 29x2.4" |
Rear mech | Shimano Cues U4000; GS |
Wheelset | 29" - Merida Comp CC II; 25mm inner rim width; material: aluminium; tubeless ready Black steel Shimano QC300; 100x9mm; 32 Spoke; Centerlock Shimano QC300-HM; 135x9mm; 32 Spoke; Centerlock |
Headset | FSA NO.55R/57SC/57B |
Stem | Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise |
Handlebar | Merida CC; material: aluminium; 15mm rise; S - 720mm wide, (M-XXL) - 750mm wide |
Shifters | Rear: Shimano Cues U4000 |
Cassette | SunRace U9 CS-U980 9AZ; 11-46 teeth; 9 speed |
Chain | KMC xGlide |
Chainset | Shimano Cues UT400-1; 32 tooth chainset; material: aluminium ; Crank length: S - 165mm, (M-XXL) - 170mm |
Bottom bracket | Shimano UN101 LL123 |
Saddle | Merida Comp SL; V-mount |
Seat post | Merida Comp CC; material: aluminium; 30.9mm diameter; in-line |
Tape grips | Merida Comp TR |
