Merida's expertise for over 50 years has been building bombproof aluminium hardtails.
The latest generation follows modern mountain bike trends - a longer reach combined with a shorter stem. The geometry features a steeper seat angle and slacker head angle for greater offroad capability but without compromising everyday usability.
The sophisticated TFS frames feature:
full internal cable routing for a clean, neat set up,
tapered headtube offering future upgrade potential
inboard disc brake mounts protect the brake and maximise stopping power
dropper post ready
New XXS Big Seven size extends the wide range of sizes; Big Nine for taller riders, Big Seven for shorter riders. Riders in the middle can take riding style into account - for speed and efficiency choose a Big Nine, for agility choose a Big Seven.
Frameset | TFS V - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 27.5" x 2.4" |
---|---|
Fork | SR Suntour XCE28; Coil; 100 mm travel; 27x2.25" max. tyre size |
Brakes | Mechanical Disc Shimano BR-M375; mechanical Disc brake with Shimano RT10; 160 mm & Shimano BR-M375; mechanical Disc brake with Shimano RT10; 160 mm |
Tyres | Kenda K1080; 27.5x2.2" & Kenda K1080; 27.5x2.2" |
Rear mech | Shimano Tourney TY300 |
Wheelset | 27.5" - Merida Comp CC; 20mm inner rim width; material: aluminium Black steel Shimano TX505; 100x9mm; 32 Spoke; Centerlock Shimano TX505; 135x9mm; 32 Spoke; Centerlock |
Headset | FSA NO.55R/57SC/57B |
Stem | Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise |
Handlebar | Merida CC; material: aluminium; 15mm rise; (XXS-XS) - 700mm wide, S - 720mm wide |
Shifters | Front: Shimano Altus EF-500-2L, Rear: Shimano Altus EF-500-7R |
Cassette | Shimano CS-HG210-7; 12-32 teeth; 7 speed |
Chain | KMC Z7 |
Chainset | Prowheel TM-CY10; 36-22 tooth chainset; material: aluminium; Crank length: 165mm |
Bottom bracket | FSA TH-7420ST; 73-127.5mm |
Saddle | Merida Sport |
Seat post | Merida CC; material: aluminium; 30.9mm diameter; 15mm layback |
Tape grips | Merida EC |
Front mech | Shimano Altus FD-M315 |
