Frameset | DT - 6061 double butted technoformed aluminium. BSA BB standard, 135 x 9mm QR axle standard. Mounting points for rack, mudguards and kickstand. Max tyre size 700 x 42c |
---|---|
Fork | SR Suntour NEX; Coil; 63 mm travel; 700x50C max. tyre size |
Brakes | V Brake Promax MTV-117A; V-brake & Promax MTV-117A; V-brake |
Tyres | Merida K1171; 700x40C; wired & Merida K1171; 700x40C; wired |
Rear mech | Shimano RD-M310 |
Wheelset | 700c - Merida CC; 17mm inner rim width; material: aluminium Steel UCP Joytech JY-751DSE; 100x9mm; 32 Spoke Joytech JY-752DSE; 135x9mm; 32 Spoke |
Headset | FSA TH888 |
Stem | Merida TK; material: aluminium; 25.4 mm diameter; adjustable |
Handlebar | Merida CC; material: steel; 620mm wide; 30mm rise |
Shifters | Front: Shimano ST-EF500-L, Rear: Shimano ST-EF500-7R |
Cassette | Shimano MF-TZ500; 14-28 teeth; 7 speed |
Chain | Sunrace CNM84 |
Chainset | Shimano TY301; 48-38-28 tooth chainset; material: aluminium; Crank length: (XXS-M) - 170mm, (M/L up) - 175mm |
Bottom bracket | FSA TH-7420ST, 68-124 |
Saddle | Merida Cross Sport |
Seat post | Merida TK; 27.2mm diameter; 13mm layback; 40mm seat post travel |
Tape grips | Merida EC |
Front mech | Shimano FD-TY510-3 |
