| Frameset | TFS IV - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 50c |
|---|---|
| Fork | SR Suntour NEX HLO; Coil; 63 mm travel; Lockout; 700x48C max. tyre size |
| Brakes | Hydraulic Disc Shimano MT200; 2 piston with Shimano RT10; 160mm & Shimano MT200; 2 piston with Shimano RT10; 160mm |
| Tyres | Kenda Ambra K1278; 700x45C; wired; reflective stripe & Kenda Ambra K1278; 700x45C; wired; reflective stripe |
| Rear mech | Shimano CUES U3020; SGS |
| Wheelset | 700c - Merida Comp TK; 20mm inner rim width; 17mm rim depth; material: aluminium Black stainless Shimano QC300; 100x9mm; 32 Spoke; Centerlock Shimano QC300-HM; 135x9mm; 32 Spoke; Centerlock |
| Headset | Merida M2346 Neck |
| Stem | Merida Comp CC; material: aluminium; 31.8 mm diameter; 17° degree rise; Length: 90mm |
| Handlebar | Merida Comp CC; material: aluminium; 680mm wide; 15mm rise |
| Shifters | Front: Shimano CUES U4000, Rear: Shimano CUES U4000 |
| Cassette | Shimano LG300; 11-36 teeth; 9 speed |
| Chain | KMC xGlide |
| Chainset | Shimano CUES U4000; 40-26 tooth chainset; Crank length: (XXS-S) - 170mm, (M-XL) - 175mm |
| Bottom bracket | Shimano BB-UN101; 73mm |
| Saddle | Merida Comp TK |
| Seat post | Merida Comp CC; material: aluminium; 30.9mm diameter; 5mm layback |
| Tape grips | Merida Comp TK |
| Front mech | Shimano CUES U4000 |
