The eOne-Sixty is the headline grabber of the Merida eBike range; for 3 generations it's been winning tests, gathering accolades and generally hogging the limelight!
The eOne-Forty shares exactly the same frame and design features but has different ride characteristics.
The shock stroke on the eOne-Forty is shorter, reducing rear travel to 133mm and creating a steeper seat angle. The shorter 140mm fork extends the reach, delivering a slightly steeper head angle. In combination these small changes make the eOne-Forty more agile and playful; a highly competent climber that's perfect for all day riding.
The mixed wheel size set up is carried over, to give the e-full suspension bikes precise steering, fantastic €˜rolling over obstacles €™ behaviour yet maximum traction, a 29er front wheel with a 2.5" tyre is combined with a 650B rear wheel, equipped with a slightly wider 2.6" tyre. The perfect combination of precision, playfulness and traction.
All eOne-Forty models use the powerful Shimano EP8 85NM motor and bigger 630Wh battery (with the exception of frame size - S which uses 504Wh).
Shimano's e-Tube app allows you to tailor power delivery to suit your riding style; you can set two profiles; one for shredding and one for cruising.
Frameset | Lite III - Hydroformed 6061 double butted aluminium with intergrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8". |
---|---|
Fork | FOX Rhythm 34 Float eMTB+; Air; 140mm travel; Tapered; 51mm fork offset. Max. tyre size: 29" x 2.5" |
Brakes | Hydraulic disc |
Tyres | Maxxis Rekon; 29" x 2.4"; kevlar bead; 3C EXO MaxxTerra - Maxxis Rekon; 27.5" x 2.6"; kevlar bead; TR 3C EXO MaxxTerra |
Rear mech | Shimano XT RDM8100 Shadow+ 12 |
Wheelset | Merida Expert TR; 29mm inner rim width; Aluminium; Tubeless ready (tubeless tape and valves not included) |
Headset | Merida-8152 |
Stem | Merida Expert eTRII; aluminium; 35mm diameter; 0 degree rise - Stem length: 50mm (all sizes). GoPro & Supernova mount point. |
Handlebar | Merida Expert eTR; 780mm wide; 20mm rise |
Shifters | Shimano Deore SL-M6100 12 speed with Shimano SL -MT500-IL lever |
Cassette | KMC e12T EPT |
Chain | KMC e12T EPT |
Chainset | Shimano CRE80-12-B; 34 tooth chainring with Shimano FCEM600; 165mm length crank |
Bottom bracket | Part of Shimano Steps motor |
Saddle | Merida Expert CC; V-mount including Merida multitool |
Seat post | Merida Expert TR; 30.9mm diameter; in-line; Drop: 100mm (S), 125mm (M), 150mm (L/XL), 170mm (XXL) |
Motor | 630 Wh |
Rear shock | RockShox Deluxe Select+; platform |
Tape grips | Merida Expert EC |
