It’s all about lightweight for kids; all our bikes have rigid forks as cheap suspension forks tend to work poorly and weigh a lot. We use 1x drivetrains with trigger shifters to keep shifting simple, further reducing the overall weight.
All components are as light and child-focused as possible. The flip-flop stem and spacers allow for growth, extending the life of the bike.
Suits heights from approx. 109-129 cm.
| Frameset | TFS - 6061 aluminium tubing, double butted and technoformed. BSA BB standard, 9mm QR axle standard. Replaceable dropout. Max tyre size 20" x 2.4" |
|---|---|
| Fork | Merida material:TS J. 20+; material: aluminium; 20x2.4" max. tyre size |
| Brakes | Hydraulic Disc Tektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-52; 160mm & Tektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-52; 160mm |
| Tyres | Maxxis Pace; 20x2.10"; wired & Maxxis Pace; 20x2.10"; wired |
| Rear mech | Microshift Acolyte Speed Super Short Cage; RD-M5180S; Super short cage |
| Wheelset | 20" - Merida JR 20+; material: aluminium Black steel KT-K68F; 100x9mm; 20 Spoke KT-TD7R-M10; 135x9mm; 24 Spoke |
| Headset | FSA NO.10P Neck15 |
| Stem | Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise |
| Handlebar | Merida Expert JR; material: aluminium; 560mm wide; 25mm rise |
| Shifters | Rear: Microshift Acolyte Quick Trigger Pro; SL-M6285-ER; Super short reach; Gear indicator; single click |
| Cassette | Sun Race M55; 11-34 teeth; 8 speed |
| Chain | KMC Z8.3 |
| Chainset | Prowheel A10PP; 32 tooth chainset; material: aluminium; Crank length: 114mm |
| Bottom bracket | Squared LL116 |
| Saddle | Merida Comp JR |
| Seat post | Merida Comp CC; 27.2mm diameter; in-line; material: aluminium |
| Tape grips | Merida Expert JR |
